Citizen CCL-S703 Type III, DT/TT, 300 DPI, USB + Ethernet + SER & w/ Standard Cutter

• 300dpi resolution printhead
• Colour LCD screen
• Print wirelessly with Standalone Forms
• Enhanced user experience with set up wizard
• USB and LAN interfaces as standard
• Optional interfaces available: Wireless LAN, Serial and Parallel
• Cross Emulation, autoswitch between Zebra® and Datamax® emulations

Benefits

• Paper exit: Front exit - prevents damage from moisture or foreign objects
• Paper width: Variable paper width - 1 inch (25.4 mm) – 4.6 inches (118.1 mm)
• Paper load: Front access for all operations including media and ribbon changing
• Printing Speed: Ultra fast print out - up to 250mm per second (10 inches per second)
• Media support: Very large media capacity - holds rolls up to 8 inches (200 mm)
• Ribbon options: Wide range of ribbon options - Uses up to 450 metres inside and outside wound ribbons
• Display: Colour LCD panel with touch control, plus two buttons
• Hi-Open™ case for vertical opening, no increase in footprint and safe closing.
• No more unreadable labels - the ARCP™ ribbon control technology assures clear prints.
• Power switch located in recess at front of printer
• Energy: Built in power supply

Media sensor:

• Black mark sensor
• Adjustable media sensor
• Label gap sensor

Tear bar: Standard tear-bar for perforated tags

• Front mounted host USB connection for peripherals and memory sticks

Specification

• Printing Technology: Thermal Transfer + Direct Thermal
• Resolution: 300 dpi
• Print Speed (Maximum): 10 inches per second (254 mm/s)
• Print Width (Maximum): 4 inches (104 mm)
• Media Type: Roll or fanfold media; die-cut, continuous, or perforated labels, tags, and tickets (inside or outside wound)
• Media Width (Min to Max): 1 - 4.6 inches (25.4 - 118 mm)
• Media Thickness (Min to Max): 63.5 to 254 µm
• Media Length (Min to Max): 0.25 to 64 inches (6.35 to 1625.6 mm)
• Roll Size (Max), Core Size: Outside diameter 8 inches (200 mm), core size 1 to 3 inches (25 to 75 mm)
• Ribbon Size: 3.4 inches (86.5 mm) maximum outside diameter, 450 metres length
• Ribbon Winding & Type: Ink side in or out, automatically sensing; wax, wax/resin, or resin type
• Ribbon System: ARCP™ automatic ribbon tension adjustment
• Mechanism: Hi-Lift™ metal mechanism with wide opening head
• Media Sensor: Fully adjustable gap, notch, and reflective black mark sensors
• Main Interface: Triple interface – USB and Ethernet built-in, plus interface card slot for optional cards

Optional Interfaces:

• Serial
• Premium Ethernet (1 Gbps)
• Compact Wireless LAN (802.11a/b/g/n)
• Parallel
• Compact LAN with remote maintenance
• Premium Wireless LAN
• Case: Hi-Open™ metal case with a safe, soft-close feature
• Control Panel: 2 buttons with a colour LCD panel and touch control
• RAM (Standard Memory): 256 MB total
• Drivers and Software: Free from the manufacturer’s website, including support for multiple platforms

Emulations (Languages):

• Datamax® DMX
• Cross-Emulation™ – auto-switch between Zebra® and Datamax® emulations
• Zebra® ZPL2®
• BASIC interpreter for data stream processing and ticketing emulations
• Eltron® EPL2®
• CBI™ BASIC Interpreter
• Size (W x D x H) and Weight: 255 x 490 x 265 mm, 13.3 Kg

Data Sheet
