BradyPrinter i5300 600 dpi with Wi-Fi and Lab ID Software
by Brady Canada
Original price
$3,055.00
-
Original price
$3,055.00
Original price
$3,055.00
$3,055.00
-
$3,055.00
Current price
$3,055.00
Product Highlight
Maximum Label/Tape Width:
4.25 in
Color Printing Capability:
Single Color
Maximum Labels per Day:
5000
Stand Alone Printing:
PC connected
Print Resolution:
600 dpi
Print Technology:
Direct Thermal, Thermal Transfer
Cut Options Available:
Cut at the end of print jobs, Cut between labels, Full Cut
Overview
Get fast and efficient precision printing for high-mix / high-volume labeling. Printer and software allow for quick label set up and no-waste material changeovers.
- 600 dpi; prints small fonts with precision
- Requires no calibration and no heat and speed setting adjustments
- 20-second material changeovers, 0.20" – 4" label widths
- Pauses, resumes and stores print jobs on printer in an adjustable queue with overwrite protection
- 7" color touchscreen and built-in auto cutter
- Solid construction with an all-metal frame
- 1-click label part recognition and setup with Brady Workstation Laboratory ID Software Suite
- Intuitive and easy to operate
Top Applications
General Identification
Directional marking, Equipment labeling
Wire and Cable
Sleeves, Self-Lams, Wire Wraps, Flag Labels, Cable Markers
Rating & Name Plate
Durable finished goods, High quality barcode images and text, UL certification
Circuit Board
ESD labels, Polyimide circuit board labels
Laboratory
Vial, Tube, Slide labeling, Sample identification
Specifications
| Key Characteristics | Product Number | 151295 |
| UPC | 754473637651 | |
| UOM | Each | |
| Trade Name | BradyPrinter i5300 | |
| Brand Name | Brady® | |
| Country of Origin | Malaysia | |
| HTS Code (Harmonized Tariff Schedule) | 8443.32.1050 | |
| ECCN (Export Commodity Control Number) | EAR99 |
| Dimensions | Dimensions | 11 in H x 11.2 in W x 15.8 in D |
| Height | 11 in | |
| Width | 11.2 in | |
| Depth | 15.8 in | |
| Display Size | 7 in | |
| Weight | 33 lb |
| Material Characteristics | Color | Blue, Gray |
| Product Features | Application | Asset Tracking, Barcode Labeling, Circuit Board Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, Facility Identification, General Identification, Laboratory Labeling, Pipe and Valve Marking, Solar Panel Labeling, Wire and Cable Labeling |
| Built-In Label Wizards | No | |
| Connectivity Options | Cabled, Ethernet, USB 2.0, USB Host | |
| Cut Options Available | Cut at the end of print jobs, Cut between labels, Full Cut | |
| Cutter Type | Auto Cutter | |
| Display Type | Color LCD Touch Screen | |
| Estimated Media Changeover Time | 15 seconds for media roll, 5 seconds for ribbon | |
| Keyboard Type | None | |
| Memory | 512 MB RAM, 195 MB IFFS Flash | |
| Stand Alone Printing | PC connected | |
| Number of Symbols | See Brady Workstation Software | |
| Plug Type | US | |
| Power Supply Voltage | 100 - 240 V @ 50 - 60 Hz | |
| Auto Shut-Off / Power Conserve | Yes | |
| Print Preview Feature? | Yes | |
| Units | Inches, mm, Points | |
| User Interface Type | PC, Touch Screen | |
| Battery Type | Internal, not removable | |
| Operating System | Windows® 10, Windows® 7, Windows® 8, Windows® Server 2012, Windows® Server 2012 R2, Windows® Server 2016 |
| Printing Specifications | Automatic Label Set Up | Yes |
| Barcode Symbologies - 2D | Aztec, Data Matrix, PDF417, QR code | |
| Barcode Symbologies - Linear | Codabar, Code 128A, Code 128B, Code 128C, Code 39, Code 93, EAN-13, EAN-8, HIBC, Interleaved 2 of 5, JAN-8, MSI, Plessey, UPC-A | |
| Calibration Required? | No | |
| Color Printing Capability | Single Color | |
| Font Sizes | 4 - 250 pt | |
| Font Styles | Arial, Courier New, Tahoma, Times New Roman, Trechuchet MS, TrueType fonts storable to printer, Verdana | |
| Maximum Labels per Day | 5000 | |
| Minimum Label Length | 0.2 in | |
| Maximum Print Speed | 5 in/s | |
| Minimum Liner Width | 0.71 in | |
| Print Resolution | 600 dpi | |
| Print Technology | Direct Thermal, Thermal Transfer | |
| Media Sensor Adjustment | Automatic Adjustment | |
| On Screen Indicators | Data Reception, Error Messaging, Ethernet Status, Ribbon and label part number recognition, Supply Remaining, WiFi |
| Compatibility | Compatible Media | B30-, B30C-, B30EP-, B33-, B33C-, B33D-, B33FP-, B33FT-, B33R- |
| Label Material Types | Direct Thermal Paper, FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Magnetic Polyester, Metal-detectable Polyester, Metallic, Non-metal Polyester, Metallized Polyester, Metallized Polyester with Polyester Overlaminate, Nylon Cloth, Paper, Phosphorescent Polyester, Polyester, Polyester with Polyester Overlaminate, Polyimide, Polyolefin, Polypropylene, Polyvinylfluoride, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallized Polyester, Vinyl, Vinyl Cloth | |
| Continuous & Die-Cut Materials Supported | Continuous and Die-cut | |
| Custom Labels Available | Yes | |
| Custom Media Parts Available | Yes | |
| Maximum Label/Tape Width | 4.25 in | |
| Maximum Print Width | 4.015 in | |
| Maximum Liner Width | 4.25 in | |
| Software Compatibility | Brady Workstation, Windows based driver for 3rd party software use | |
| Languages Available | Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional and Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (Canada), German, Hungarian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Spanish (universal), Thai, Turkish, Vietnamese |
| What's Included | Includes | (1) Brady Workstation Laboratory Identification Suite (BWS-LABS-EM), (1) BradyPrinter i5300 Industrial Label Printer, (1) Cleaning Kit, (1) Jump drive with How To Videos and 3rd Party Win Driver, (1) Power Cable, (1) QuickStart Guide, (1) Stylus, (1) USB Cable |
| Warranty (North America) | 5 Years |
| Compliance | UNSPSC | 45101519 |
| RoHS Compliance Status | Compliant with Directive 2011/65/EU and 2015/863 |
