Citizen CL-S531-II Label Printer, Direct Thermal, 300 DPI with Premium Ethernet and Wi-Fi (ES04) Long Range.

The CL-S521II offers a reliable, easily integrated industrial desktop printing solution.  These units are supplied as standard with on-board ZPL2®, Datamax® and EPL2® emulations plus CBI BASIC Interpreter programming support, offering maximum flexibility and easy compatibility with other applications.

• Handles a range of media types, including specialized labels and wristbands.
• Powerful on-board 32 bit processor for fast output
• 32Mb of RAM and 16Mb of flash

Benefits

• Paper width: Variable paper width - 0.8 inches (19.5 mm) – 4.6 inches (118 mm)
• Paper load: Durable design - Citizen's proven Hi-Lift™ all-metal mechanism
• Printing Speed: Fast print out - 6 inches per second (150 mm per second)
• Media support: Large media capacity - holds rolls up to 5 inches (127 mm)
• Paper thickness: Paper thickness up to 0.250mm
• Hi-Open™ case for vertical opening, no increase in footprint and safe closing.
• Low space requirement - integrated power supply enables clean work station
• Case colour: Available in black or white
• Energy: Internal power supply for reliability
• Media sensor: Black mark sensor
• Adjustable media sensor
• Label gap sensor

Tear bar: Standard tear-bar for perforated tags

Specification

• Printing Technology: Direct Thermal
• Resolution: 203 dpi
• Print Speed (Maximum): 6 inches per second (150 mm/s)
• Print Width (Maximum): 4 inches (104 mm)

Media Specifications

• Media Width (Min to Max): 0.5 - 4.6 inches (12.5 - 118 mm)
• Media Thickness (Min to Max): 63.5 to 254 µm
• Media Length (Min to Max): 0.25 to 99.99 inches (6.35 to 2539.74 mm)

Roll Size (Max), Core Size:

• Inside Diameter: 5 inches (125 mm)
• External Diameter: 8 inches (200 mm)
• Core Size: 1 inch (25 mm)

Mechanism and Sensors

• Mechanism: Hi-Lift™ metal mechanism with wide opening head
• Media Sensor: Fully adjustable gap, notch, and reflective black mark

Connectivity

• Main Interface:
• Serial (RS-232C)
• USB 2.0 (Full speed)

Optional Interfaces:

• Parallel (IEEE 1284 compliant)
• Wireless LAN (802.11b/g standards; up to 100 meters, 64/128-bit WEP, WPA, up to 54Mbps)
• Ethernet (10/100 BaseT)

Case and Control Panel

• Case: Hi-Open™ metal case with safe, soft-close feature
• Control Panel: 4 buttons and 4 LEDs

Memory

• Flash (Non-Volatile Memory): 16 MB total (4 MB available for user)
• RAM (Standard Memory): 32 MB total (8 MB available for user)

Software and Drivers

• Drivers and Software: Free-of-charge from website, supporting various platforms

Emulations (Languages):

• Citizen Original Commands
• Datamax® DMX
• Cross-Emulation™ (autoswitch between Zebra® and Datamax®)
• Zebra® ZPL2®
• CBI™ BASIC Interpreter
• EPL-2®

Dimensions and Weight

• Size (W x D x H): 231 x 289 x 183 mm
• Weight: 3.6 Kg

Cutter

• Type: Guillotine, Dealer Installable

Data Sheet
